Vertical Concrete Mixer Concrete Testing Equipment
Description:
Flat mouth mixer is a new type of concrete mixer, which is suitable
for general highways, power stations, dam construction projects,
construction sites, roads, bridges, hydropower and large and
medium-sized prefabrication plants. It has the advantages of stable
operation, less energy consumption, compact structure, reliable
transmission, light weight, production, etc. It can mix plastic,
dry and hard, flowing concrete, light aggregate and mortar.
The flat mouth mixer is driven by a reducer. It can mix plastic and
semi dry concrete in a forward rotation and discharge in a reverse
rotation when working. It can be combined with the batching machine
to form a small and medium-sized mixing station. The unloading is
fast and clean, and the maintenance is convenient, labor-saving and
beautiful. It is suitable for general construction sites, roads,
bridges, water and electricity projects.
Concrete Testing Equipment
Specification:
| Parameters of vertical flat mouth mixer |
| Product model | JW300 | JW400 | JW500 | JW750 | JW1000 | JW2000 | JW3000 |
| Product diameter(m) | 0.9M | 1.1M | 1.3M | 1.5M | 1.8M | 2M | 2M-3M |
| Mixing arm | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| Mixing capacity | 0.2m³ | 0.3m³ | 0.5m³ | 0.7m³ | 1m³ | 1.5m³ | 2m³-5m³ |
| Cylinder thicknes(mm) | 4/6/8 | 4/6/8 | 4/6/8 | 6/8 | 6/8 | 6/8 | 6/8/10 |
| Base plate thickness(mm) | 6/8 | 6/8 | 8/10 | 8/10 | 8/10 | 8/10 | 10/12 |
| Transmission type | Flat box/half pack | Flat box/half pack | Flat box/full bridge | Half package/full bridge | Half package/full bridge | Full axle/two-stage acceleration | Full axle/two-stage acceleration |
| Oil quantity(L) | 4L | 4L | 6L | 6L | 6L | 8L | 10L |
| Weight(kg) | 150kg | 230kg | 480kg | 550kg | 680kg | 750kg | 900kg |
| Motor power(kw) | 4kw | 5.5kw | 7.5kw | 11kw | 15kw | 15kw-16kw | 18.5kw-22kw |
| Dimension(M) | 0.9*0.9*1.1 | 1.1*1.1*1.1 | 1.3*1.3*1.3 | 1.5*1.5*1.3 | 1.8*1.8*1.3 | 2.0*2.0*1.7 | 2.5*2.5*1.7 |
| Scope of application | Construction site | Mortar mixing | Concrete | Feed | Concrete | Secondary storage mixing tank | Secondary storage mixing tank |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS &
INTERTEK certificated, one hour reach Tianjin port, this is how we
keep good quality and competitive prices for global valued
customers.
Our main products cover Universal testing machine, Compression
testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks,
Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids,
Geotextiles, Textiles, Environmental,General Equipment,Universal
Testing Equipment.BTUTEST is exporting its products to more than 60
countries by offering its services through its authorized
distributors and representatives.
Our main customers are private and research testing laboratories,
road and general contractors, concrete and cement manufacturers,
asphalt manufacturers, government authorities, ministries,
engineers, consultants and re-seller. We also cooperate with
accredited research centers and the most important universities in
the world.we can supply more top quality product and service for
more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to
video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16
years focusing on test instruments field. warmly welcome to visit
our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange
shipment within 7 days. Please be aware that our production lead
times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional
after-sale service team will provide perfect technical support. And
help the customer solve problems encountered while using our
product, handles problems and complaints professionally and timely.
Each instruments must be carried out 100% quality examination and
test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the
standard exporting wooden case, which not only has good shock
absorption, impact resistance, heat SSO has the advantages of
nontoxic, odorless, moisture corrosion, good transparency etc.
