Motorized Soil Testing Equipment Hydraulic Specimen Extruder

    Buy cheap Motorized Soil Testing Equipment Hydraulic Specimen Extruder from wholesalers

    Buy cheap Motorized Soil Testing Equipment Hydraulic Specimen Extruder from wholesalers
    • Buy cheap Motorized Soil Testing Equipment Hydraulic Specimen Extruder from wholesalers
    • Buy cheap Motorized Soil Testing Equipment Hydraulic Specimen Extruder from wholesalers
    • Buy cheap Motorized Soil Testing Equipment Hydraulic Specimen Extruder from wholesalers
    • Buy cheap Motorized Soil Testing Equipment Hydraulic Specimen Extruder from wholesalers

    Motorized Soil Testing Equipment Hydraulic Specimen Extruder

    Ask Lasest Price
    Brand Name : Btutest
    Model Number : BTU
    Certification : SGS, INTERTEK
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000 sets per month
    Delivery Time : 5-8 work days Soil Testing Equipment
    • Product Details
    • Company Profile

    Motorized Soil Testing Equipment Hydraulic Specimen Extruder

    Motorized Hydraulic Specimen Extruder Soil Testing Equipment

    Main purpose and scope of application:

    This machine is mainly used for demolding test pieces in various test cylinders, such as "multifunctional electric compaction instrument", "Marshall electric compaction instrument", and light and heavy manual compaction instruments. Soil Testing Equipment


    Applicable to:

    1. Preparation of compression test mold:? one hundred and fifty × 230mm ? one hundred × 180mm ? fifty × 130mm

    2. Light and heavy geotechnical compaction test mold:? one hundred and fifty-two × 170mm ? one hundred × 127mm

    3. Marshall compaction test mold:? one hundred and one point six × 87mm


    Specification:

    Maximum load200KN
    Range of dynamometer0-60Mpa
    Rising speed50c m/min
    Maximum working pressure of oil30Mpa
    Piston diameter? 100 mm
    Maximum piston stroke280mm
    Motor specification1100W 380V 1400 rpm
    Overall dimension600×520×1260mm
    Net weightabout 120kg



    About Us:
    260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
    Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
    Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.

    Our Advantage:
    Q1: What is your warranty ?
    A: 12 months product warranty, but lifetime for services.
    Q2: How-to video provided ?
    A: Yes. If required, our engineers will record a specialized how-to video for you.
    Q3: Are your company a trading one or a factory?
    A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
    Q4: After an order is placed, when to deliver?
    A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
    Q5: What about the after-sales service and product’s quality?
    A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments
